| Place of Origin: | CHINA |
|---|---|
| Brand Name: | Coslight or OEM |
| Certification: | UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS |
| Model Number: | FP31136227A |
| Minimum Order Quantity: | 1unit |
| Price: | USD 1498 |
| Packaging Details: | Wooden package |
| Delivery Time: | 7-30days |
| Supply Ability: | 5000units per month |
| Brand: | Coslight Or OEM | Type: | High Frequency |
|---|---|---|---|
| Input Voltage: | 12V/24V/48V | Warranty: | 3 Years |
| Application: | Home Appliance,Frequency Change,sensitive Load,Solar Power System Home | Waveform: | Pure Sine Wave |
| Protection: | Overload / Over Voltage/output Short Circuit | Capacity: | 100Ah |
| High Light: | 48v 100ah Telecom Lithium Battery,48v Telecom Lithium Battery,3KW Mppt Solar Inverter |
||
48v 100ah Telecom Lithium Battery 3KW 5KW Mppt Solar Inverter
KW Rack Mounted Solar Power Inverter , High Frequency Solar Inverter With 80A 145V MPPT
Features:
Pure sine wave inverter
Configurable input voltage range For home appliances and personal computers via LCD setting
Configurable battery charging current based on applications via LCD setting
Configurable AC Charger via LCD setting
Compatible to mains voltage or generator power
Auto restart while AC is recovering
Overload/Over temperature/short circuit protection
Smart battery charger design For optimized battery performance
Cold start Function
TECHNICAL SPECIFICATIONS :
|
MODEL |
|
|
|
|
|---|---|---|---|---|
|
Rated output power |
3000W |
4000W |
5000W |
|
|
AC INPUT |
||||
|
Nominal Input Voltage |
220Vac |
|||
|
Selectable Voltage range |
AC 185V~270V |
|||
|
Frequency Range |
50Hz/60Hz (Auto sensing) |
|||
|
Inverter Efficiency(Peak) |
97% |
|||
|
INVERTER OUTPUT |
||||
|
Output voltage waveform |
Pure sine wave |
|||
|
Output Voltage Regulation |
220Vac ± 5% |
|||
|
Output Frequency |
50Hz |
|||
|
Power Factor |
1 |
|||
|
Transfer Time |
10ms typical |
|||
|
Peak Efficiency |
92% |
|||
|
Nominal DC Input Voltage |
48VDC |
|||
|
Cold Start Voltage |
46VDC |
|||
|
Output Short Circuit Protection |
Line mode |
Circuit Breaker |
||
|
Battery mode |
Electronic Circuits |
|||
|
BATTERY |
||||
|
Battery voltage |
48VDC ( ±0.5) |
|||
|
Floating voltage |
54V |
|||
|
CHARGER |
||||
|
Charging Current(UPS) @Nominal Input Voltage |
Default:30A; MAX:60A |
|||
|
Bulk Charging Voltage |
56.4Vdc |
|||
|
Floating Charging Voltage |
54Vdc |
|||
|
Charging Algorithm |
3-Step |
|||
|
GENERAL |
||||
|
Mounting |
Rack mount |
|||
|
Display |
LED+LCD |
|||
|
Safety Certification |
CE |
|||
|
Operation Temperature Range |
0℃ to 40℃ |
|||
|
Storage Temperature |
-15℃ to 60℃ |
|||
|
Dimensions (W*H*D)(mm) |
400×468×86.3 |
|||
|
Net Weight (kg) |
10.0 |
|||
