| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Coslight |
| Certification: | UL |
| Model Number: | 12V-60Ah |
| Minimum Order Quantity: | 500 units |
| Price: | $143.00 - $148.00/units |
| Packaging Details: | wooden packing |
| Supply Ability: | 500 Unit/Units per Month |
| Warranty: | 3months-1year | Anode Material: | Other |
|---|---|---|---|
| Chargeable: | Yes | Application: | Toys, Power Tools, Consumer Electronics, Electric Bicycles/Scooters, Solar Energy Storage Systems |
| Battery Size: | 12V60Ah | Weight: | 7 Kg |
| The Charging Ratio: | 60 A | The Discharge Rate: | 60 A |
| Energy: | 768 Wh | Cycle Life: | 2000+cycles @ 1C 80% DOD |
| Self Discharge: | <3% Per Month | Monthly Self Discharge: | Less Than 3.5% |
| Charge Temperature: | 0~45 ℃ | Discharge Temperature: | -20℃ To 60 ℃ |
| Storage Temperature: | -20℃ To 45 ℃ | Height: | 205± 2 Mm |
| Case Material: | ABS | Enclosure Protection: | IP65 |
| Port: | Sz/hk | ||
| Highlight: | 12v 60ah Lithium Iron Phosphate Battery,12v 60ah lithium phosphate battery,IP65 lithium phosphate battery |
||
|
ELECTRICAL SPECIFICATIONS
|
|
|
|
Nominal Voltage
|
12.8 V
|
|
|
Nominal Capacity @ 0.2C
|
60 Ah
|
|
|
Energy
|
768 Wh
|
|
|
Resistance
|
150mΩ
|
|
|
Cycle Life
|
2000+cycles @ 1C 80% DOD
|
|
|
E⃞iciency
|
99%
|
|
|
Self Discharge
|
<3% per Month
|
|
|
Maximum Modules in Series/Parallels
|
4S or 4P
|
|
|
CHARGE & DISCHARGE SPECIFICATIONS
|
|
|
|
Monthly Self Discharge
|
Less than 2%
|
|
|
E⃞iciency of Charge
|
100% @ 0.5 C
|
|
|
E⃞iciency of Discharge
|
96 - 99% @ 1 C
|
|
|
Charge Voltage
|
14.6 ± 0.2 V
|
|
|
Charge Model CC & CV
|
0.2C to 14.6 V ,
then 14.6V, charge current to 0.02C |
|
|
Standard Charge Current
|
12 A
|
|
|
Max. Charge Current
|
60 A
|
|
|
Max. Continuous Discharge Current
|
60 A
|
|
|
Peak Discharge Current
|
120 A (3S)
|
|
|
BMS Discharge Cut-o⃞ Voltage
|
10 V
|
|
|
Charge Temperature
|
0~45 ℃
|
|
|
Discharge Temperature
|
-20℃ to 60 ℃
|
|
|
Storage Temperature
|
-20℃ to 45 ℃
|
|
|
MECHANICAL SPECIFICATIONS
|
|
|
|
Length
|
138± 2 mm
|
|
|
Width
|
229 ± 2 mm
|
|
|
Height
|
205± 2 mm
|
|
|
Weight
|
7 Kg
|
|
|
Case Material
|
ABS
|
|
|
Terminal
|
M5
|
|
|
Enclosure Protection
|
IP65
|
|
|
COMPLIANCE
|
|
|
|
Certifications |
UL1642 (cells)
IEC62133 (cells) |
|
|
Shipping Classification
|
UN 3480, CLASS 9
|
|
