| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Coslight |
| Model Number: | CPB |
| Minimum Order Quantity: | 50 pieces |
| Price: | $1,958.00/pieces >=50 pieces |
| Packaging Details: | wooden packing |
| Supply Ability: | 50 Unit/Units per Month |
| Protection Level: | IP20 | External Size: | 620W*345D*780mm |
|---|---|---|---|
| Nominal Voltage: | 51.2V | Voltage Range: | 45~57.6V |
| Capacity: | 10.24KWH ( 2.5kWH*4 ) | Rated Power: | 5000W |
| Humidity: | 5%~95% | Weight Approx.: | 140KG |
| Port: | Sz/hk | ||
| High Light: | 5000W Home Energy Storage Battery,IP20 Home Energy Storage Battery,IP20 home battery storage |
||
|
Battery
|
Nominal Voltage
|
51.2V
|
|
|
Voltage Range
|
45~57.6V
|
|
|
Capacity
|
10.24KWH ( 2.5kWH*4 )
|
|
|
Max.discharge Rate
|
1C
|
|
|
Max.charge Rate
|
1C
|
|
|
Battery Type
|
Li-ion(LFP)
|
|
AC Output
|
Rated Power
|
5000W
|
|
|
Surge Power
|
10000w
|
|
|
Output Voltage
|
220/230/240Vac±3%
|
|
|
Output Current
|
22A
|
|
|
Rated Frequency
|
50/60Hz
|
|
|
VTHD
|
＜3%
|
|
|
Output Wave
|
Pure Sine Wave
|
|
|
Output Type
|
Euro Round Socket×4+Terminal
|
|
|
Max. Efficiency
|
93%
|
|
AC Input
|
AC Input Voltage Range
|
170~280Vac
|
|
|
AC Input Frequency
|
50/60Hz
|
|
|
Max AC Charge Current(Battery)
|
30A(0~60A Adjustable)
|
|
PV Input
|
Max. PV Power(Recommended)
|
6000W
|
|
|
Max. PV Voltage
|
450V
|
|
|
MPPT Range
|
120V~430V
|
|
|
Max PV Charge Current(Battery)
|
100A
|
|
Operating Conditions
|
Operating Temperature
|
0~55℃
|
|
|
Storage Temperature
|
-15℃~60℃
|
|
|
Humidity
|
5%~95%
|
|
|
Cooling Strategy
|
Fan
|
|
|
Weight
|
Approx. 140KG
|
|
|
Dimension [W x H x D, mm]
|
620W*345D*780mm
|
|
|
Packing
|
wooden case
|
|
|
Packing Dimension [W x H x D]
|
TBD
|
|
|
IP class
|
IP20
|
|
|
Communication
|
WIFI/RS485
|
|
|
Warranty
|
3 years
|
FAQ
Q: Are you a manufacturer or a trade company?
A: We are a manufacture. You are warmly welcome to visit our factory if you have interest!
Q: Is OEM/ODM available?
A: Yes, it is. Please feel free to tell us your application and your basic battery requirements.Our R&D team will be pleasure to provide a full solution to you with these factors taken into consideration.
Q: Can you provide samples for testing use?
A: Yes, we can. After discussion and designing with our sales and engineer, we recommend client to order samples first to test our battery quality and stability.
Q: What security protection function does the PCM have?
A: Short circuit protection, over-current protection, over-load protection, over-discharge protection, inversely-connection protection, temperature control, balance, fuse, thermistor, etc. Our engineer will choose particular function to use for you.
Q: Are there related certificates about battery?
A: If required, we could apply CE, ROHS, CB(IEC62133), UL, KC, PSE, BIS, UN38.3 etc.
Q: How long for the warranty?
A: Normally 1-3 year.
Q: Which payment methods do you accept?
A: Usually, we accept Western Union, TT, LC. etc.
