| Place of Origin: | Guangdong, China |
|---|---|
| Model Number: | CPW5000 |
| Minimum Order Quantity: | 50 units |
| Price: | $1,600.00/units >=50 units |
| Packaging Details: | wooden packing |
| Supply Ability: | 50 Unit/Units per Month |
| Battery Type: | Li-ion(LFP) | Nominal Voltage: | 51.2V |
|---|---|---|---|
| Voltage Range: | 45~57.6V | Max.discharge Rate: | 1C |
| Max.charge Rate: | 1C | Operating Temperature: | 0~55℃ |
| Storage Temperature: | -15℃~60℃ | Humidity: | 5%~95% |
| Product Weight: | 63kg | Enclosure Protection Rating: | IP20 |
| Warranty: | 2 Years | Port: | Sz/hk |
| High Light: | 51.2V Off Grid Power Supply,5kwh Off Grid Power Supply,5kwh off grid supply |
||
|
Models
|
CPW5000
|
|
|
|
Battery
|
Nominal Voltage
|
51.2V
|
|
|
|
Voltage Range
|
45~57.6V
|
|
|
|
Capacity
|
5KWH
|
|
|
|
Max.discharge rate
|
1C
|
|
|
|
Max.charge rate
|
1C
|
|
|
|
Battery Type
|
Li-ion(LFP)
|
|
|
AC Output
|
Rated Power
|
5000W
|
|
|
|
Surge Power
|
10000W
|
|
|
|
Output Voltage
|
220/230/240Vac
|
|
|
|
Output Current
|
22A
|
|
|
|
Rated Frequency
|
50/60Hz
|
|
|
|
VTHD
|
＜3%
|
|
|
|
Output Wave
|
Pure Sine Wave
|
|
|
|
Output Type
|
Euro Round Socket×2+Terminals
|
|
|
|
Max. Efficiency
|
93%
|
|
|
AC Input
|
AC Input Voltage Range
|
170-280VAC
|
|
|
|
AC Input Frequency
|
50/60Hz
|
|
|
|
Max AC Charge Current(Battery)
|
30A(0~60A Adjustable)
|
|
|
PV Input
|
Max. PV Power(Recommended)
|
6000W
|
|
|
|
Max. PV Voltage
|
450V
|
|
|
|
MPPT Range
|
120V~430V
|
|
|
|
Max PV Charge Current(Battery)
|
100A
|
|
|
Operating Conditions
|
Operating Temperature
|
0~55℃
|
|
|
|
Storage Temperature
|
-15℃~60℃
|
|
|
|
Humidity
|
5%~95%
|
|
|
|
Cooling Strategy
|
Fan
|
|
|
|
Product Weight
|
63kg
|
|
|
|
Dimension [W x H x D]
|
585*606*230mm
|
|
|
|
Packing
|
wooden case
|
|
|
|
Packing Dimension [W x H x D]
|
630*738*275mm (75KG)
|
|
|
|
Enclosure Protection Rating
|
IP20
|
|
|
|
Communication
|
WIFI/RS485
|
|
|
|
Warranty
|
2 years
|
|
