| Place of Origin: | Guangdong, China |
|---|---|
| Brand Name: | Coslight |
| Model Number: | FP31136282A-100Ah |
| Minimum Order Quantity: | 1000 pieces |
| Price: | $68.00 - $72.00/pieces |
| Packaging Details: | wooden packing |
| Supply Ability: | 1000 Unit/Units per Month |
| Application: | Toys, Power Tools, Consumer Electronics, Electric Bicycles/Scooters, Solar Energy Storage Systems | Weight: | 2.35±0.04 Kg |
|---|---|---|---|
| The Charging Ratio: | 100A (1 C) | The Discharge Rate: | 300A (3C) |
| Port: | Sz/hk | ||
| High Light: | 3.2v 100ah Lifepo4 Battery Cells,100ah Lifepo4 Battery Cells,Rechargeable lifepo4 prismatic cells |
||
|
Item
|
Condition / Note
|
Specification
|
|
2.1 Capacity
|
Nominal charge / discharge at 25℃
|
≥100Ah
|
|
2.2 Nominal Voltage
|
Average for nominal discharge
|
3.2 V
|
|
2.3 Operating Voltage Range
|
0%～100% SOC
|
2.50 ~ 3.70 V
|
|
2.4 Nominal Charge
|
Constant current
Constant voltage End condition (Cut off) |
50 A (0.5 C) 3.70 V
2 A |
|
2.5 Charge Current (25℃) |
Fast Continuous Charge current
|
100A (1 C)
|
|
|
Max Continuous Charge Current
|
100A (1 C)
|
|
2.6 Nominal Discharge
|
Constant current
End voltage(Cut off) |
50A (0.5 C)
2.50 V |
|
2.7 Discharge Current (25℃)
|
Max Continuous Discharge Current
|
300A (3C)
|
|
2.8 Weight
|
/
|
2.35±0.04 kg
|
|
2.9 Operating Temperature
&Humidity |
Charge
|
5 ~ 45℃, ≤85%RH
|
|
|
Discharge
|
-20～60 ℃, ≤85%RH
|
|
2.10 Storage Temperature |
≤1M
|
-20 ~ 60℃, 50%SOC
|
|
|
≤3M
|
-20 ~ 45℃, 50%SOC
|
|
|
≤12M |
-20 ~ 25℃, 50% SOC
After every tree months, 100% DOD is needed before recharged to 50% SOC |
|
Overall Dimensions(mm) |
Thickness*Width*Height
|
32*136*269.2
|
|
|
Cell height with terminals
|
282.7
|
|
|
Distance between terminals
|
57±0.5；Symmetry
|
|
|
Center distance of the terminals
|
65±0.5
|
|
|
Terminal position
|
Symmetry
|
|
|
Terminal Length*Width*Height
|
(Φ8±0.05)*(9.5±1)
|
|
|
Flatness of terminals
|
<0.25
|
|
|
Length * width of OPSD
|
Φ11±0.05
|
