Anode Material: | Other | Application: | Toys, Power Tools, Consumer Electronics, Electric Bicycles/Scooters, Solar Energy Storage Systems |
---|---|---|---|
Weight: | 13.2 Kg | The Charging Ratio: | 50 A |
The Discharge Rate: | 50 A | Energy: | 1280 Wh |
Cycle Life: | 2000+cycles @ 1C 80% DOD | Self Discharge: | <3% Per Month |
Monthly Self Discharge: | Less Than 2% | Charge Temperature: | 0~45 ℃ |
Discharge Temperature: | -20℃ To 60 ℃ | Storage Temperature: | -20℃ To 45 ℃ |
Height: | 230 ± 2 Mm | Case Material: | ABS |
Enclosure Protection: | IP65 | Port: | Sz/hk |
High Light: | Rechargeable Lithium Iron Phosphate Batteries,12.8v Lithium Iron Phosphate Batteries,12.8v 100ah Energy Storage Battery |
Product Specification
ELECTRICAL SPECIFICATIONS |
|
||
Nominal Voltage |
12.8 V |
||
Nominal Capacity @ 0.2C |
100 Ah |
||
Energy |
1280 Wh |
||
Resistance |
50mΩ |
||
Cycle Life |
2000+cycles @ 1C 80% DOD |
||
E⃞iciency |
99% |
||
Self Discharge |
<3% per Month |
||
Maximum Modules in Series/Parallels |
4S or 4P |
CHARGE & DISCHARGE SPECIFICATIONS |
|
||
Monthly Self Discharge |
Less than 2% |
||
E⃞iciency of Charge |
100% @ 0.5 C |
||
E⃞iciency of Discharge |
96 - 99% @ 1 C |
||
Charge Voltage |
14.6 ± 0.2 V |
||
Charge Model CC & CV |
0.2C to 14.6 V , |
||
Standard Charge Current |
25 A |
||
Max. Charge Current |
50 A |
||
Max. Continuous Discharge Current |
50 A |
||
Peak Discharge Current |
100 A (3S) |
||
BMS Discharge Cut-o⃞ Voltage |
10 V |
||
Charge Temperature |
0~45 ℃ |
||
Discharge Temperature |
-20℃ to 60 ℃ |
||
Storage Temperature |
-20℃ to 45 ℃ |
MECHANICAL SPECIFICATIONS |
|
||
Length |
172 ± 2 mm |
||
Width |
328 ± 2 mm |
||
Height |
230 ± 2 mm |
||
Weight |
13.2 Kg |
||
Case Material |
ABS |
||
Terminal |
M8 Screw |
||
Enclosure Protection |
IP65 |
COMPLIANCE |
|
||
|
UL1642 (cells) |
||
Shipping Classification |
UN 3480, CLASS 9 |
