Deep Cycle 12V Solar Street Light Battery Golf Cart EV lifepo4 100Ah

Basic Information
Place of Origin: CHINA
Brand Name: Coslight or OEM
Certification: UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS
Model Number: Solar Street Light
Minimum Order Quantity: 10
Price: 390.00
Packaging Details: Wooden box
Delivery Time: 10~15days
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 8000pcs/week
Application: ROAD,Highway,outdoor,courtyard,Garden Ip Rating: IP 66
Light Source: LED,Fluorescent,HID,Halogen Bulbs Working Lifetime(hour): 50000,100000
Power: 30W 60W 90W,100W Working Temperature:: -10~60℃
Capacity:: 100Ah
High Light:

12V Solar Street Light Battery


100Ah Solar Street Light Battery


100 ah 12v lifepo4 deep cycle battery

Deep Cycle 12V Solar Street Light Battery Golf Cart EV lifepo4 100Ah


Solar Battery 12V 100Ah Lithium-Ion Solar Street Light Battery Deep Cycle LED Light Golf Cart EV

Deep Cycle 12V Solar Street Light Battery Golf Cart EV lifepo4 100Ah 0

Key Features :
♦Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than a lead-acid battery, helping to minimize replacement cost and reduce the total cost of ownership
♦Lighter Weight: About 40% of the weight of a comparable lead-acid battery. A " drop-in" replacement for lead-acid batteries
♦Higher Power: Delivers twice the power of a lead-acid battery, even high discharge rate, while maintaining a high energy capacity
♦Wider Temperature Range: -20℃~60℃
♦Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation
Applications :
♦Wheelchairs and scooters
♦Solar/wind energy storage
♦Back-up power for small UPS
♦Golf trolleys & buggies
♦Electric bikes


Deep Cycle 12V Solar Street Light Battery Golf Cart EV lifepo4 100Ah 1


General Parameter
Rated Capacity
Standard discharge(0.2C5A) after Standard charge
Nominal Voltage
Mean Operation Voltage
Voltage at end of
Discharge Cut-off Voltage
Charging Voltage
Internal Impedance
Internal resistance measured at AC 1KHZ after 50% charge
The measure must use the new batteries within one week after shipment and cycles less than 5 times standard
Standard charge
Constant Current 0.2C5A
Constant Voltage 4.2V
0.01 C5A cut-off
Fast charge
Constant Current 0.5C5A
Constant Voltage 4.2V
0.01 C5A cut-off
Maximum Continuous Charge Current
0.5 C5A
Maximum Continuous Discharge Current
Operating Temperature
Charge at a very low temperature such as blew 0℃, will beget a lower capacity and reduce the cycle life of the battery cycle
Cycle Life
Storage Temperature Range
Do, not storage exceed a half year. Must charge once when stored for half a year. must charge the battery which with protects the circuit
when storage for three months.


Rated Capacity 100Ah
Minimal Capacity 98Ah
Nominal Voltage 12.8V

Discharge cut-off voltage 2.0V/cell(≥8.0V)
Charging cut-off voltage 3.9V/cell(≤15.6V)

Maximum Continuous Charge Current 40A@20℃
Maximum Continuous Discharge Current 40A@20℃
Operation Temperature Range Charge: 0~45℃
Discharge: -20~60℃
Storage Temperature Range Less than 1 year: 0~25℃
Less than 3 months: -5~35℃

Approx. Weight 13.5Kg

Dimension L330*W170*H220mm

1. Q: OEM OR ODM accepted?
Yes, we can do OEM&ODM. Logos on the power station is available.
2. Q: How to become your dealer and the requirement?
Just feel free to contact us by mail. We have very competitive prices, high-quality assurance, and the best support for our agents and dealer.
3. Q: Can I get some samples?
Yes, of course. We are honored to offer you samples, And usually, samples can be ready in 3days.
