Coslight UPS 12.8V Solar Street Light Battery For LED Street Lamp

Basic Information
Place of Origin: CHINA
Brand Name: Coslight or OEM
Certification: UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS
Model Number: Solar Street Light
Minimum Order Quantity: 10
Price: 100.00
Packaging Details: Wooden box
Delivery Time: 10~15days
Payment Terms: L/C, D/A, T/T, Western Union
Supply Ability: 8000pcs/week
Application: ROAD,Highway,outdoor,courtyard,Garden Ip Rating: IP 66
Light Source: LED,Fluorescent,HID,Halogen Bulbs Working Lifetime(hour): 50000,100000
Power: 30W 60W 90W,100W Working Temperature:: -10~60℃
Capacity:: 100Ah
High Light:

12.8V Solar Street Light Battery

,

UPS Solar Street Light Battery

,

lifepo4 battery 12.8 v

Coslight UPS 12.8V Solar Street Light Battery For LED Street Lamp



LiFePo4 Battery For 12.8V Solar System UPS Street Light LED Street Lamp



Coslight UPS 12.8V Solar Street Light Battery For LED Street Lamp 0

Key Features :
♦Longer Cycle Life: Offers up to 20 times longer cycle life and five times longer float/calendar life than a lead-acid battery, helping to minimize replacement cost and reduce the total cost of ownership
♦Lighter Weight: About 40% of the weight of a comparable lead-acid battery. A " drop-in" replacement for lead-acid batteries
♦Higher Power: Delivers twice the power of a lead-acid battery, even high discharge rate, while maintaining a high energy capacity
♦Wider Temperature Range: -20℃~60℃
♦Superior Safety: Lithium Iron Phosphate chemistry eliminates the risk of explosion or combustion due to high impact overcharging or short circuit situation



Li-Ion Batteries Backup System Lithium-Ion Lifepo4 Solar Street Lamp Lights 12V Rechargeable Pack Light With Inbuilt Battery
Usage
Capicity (Ah)
Nominal Voltage(V)
Waterproof
solar street light & CCTV camara
30ah 50ah 70ah 100ah
12V 24V 36V
IP67
OEM and ODM is warmly welcomed for other voltage and capacity.



Applications :
♦Wheelchairs and scooters
♦Solar/wind energy storage
♦Back-up power for small UPS
♦Golf trolleys & buggies
♦Electric bikes

Coslight UPS 12.8V Solar Street Light Battery For LED Street Lamp 1

Coslight UPS 12.8V Solar Street Light Battery For LED Street Lamp 2



Specification
Item
General Parameter

Remark
Rated Capacity
Typical
100Ah
Standard discharge(0.2C5A) after Standard charge
Minimum
98Ah
Nominal Voltage
12.8V
Mean Operation Voltage
Voltage at end of
Discharge
14.6V
Discharge Cut-off Voltage
Charging Voltage
12.8V


Internal Impedance
≤100mΩ
Internal resistance measured at AC 1KHZ after 50% charge
The measure must use the new batteries within one week after shipment and cycles less than 5 times standard standard
Standard charge
Constant Current 0.2C5A
Constant Voltage 4.2V
0.01 C5A cut-off

Fast charge
Constant Current 0.5C5A
Constant Voltage 4.2V
0.01 C5A cut-off

Maximum Continuous Charge Current
0.5 C5A

Maximum Continuous Discharge Current
1.5C5A

Operating Temperature
Charge
0~45℃
60±25%R.H.
Charge at a very low temperature such as blew 0℃, will beget a lower capacity and reduce the cycle life of the battery cycle cycle
Cycle Life
Discharge
-20~60℃
60±25%R.H.
Storage Temperature Range
20~25℃
60±25%R.H.
Do, not storage exceed a half year. Must charge once when stored for half a year. must charge the battery which protects the circuit
when storage for three months.




FAQ

1. Q: OEM OR ODM accepted?
Yes, we can do OEM&ODM. Logos on the power station is available.

2. Q: How to become your dealer and the requirement?
Just feel free to contact us by mail. We have very competitive prices, high-quality assurance, and the best support for our agents and dealer.

3. Q: Can I get some samples?
Yes, of course. We are honored to offer you samples, And usually, samples can be ready in 3days.
