| Place of Origin: | GuangDong,China |
|---|---|
| Brand Name: | Coslight |
| Certification: | UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS |
| Model Number: | 12v 200Ah |
| Minimum Order Quantity: | 100 pieces |
| Price: | USD430/pc |
| Packaging Details: | Wooden Box |
| Delivery Time: | 10-15days |
| Payment Terms: | T/T |
| Supply Ability: | 5000pcs per month |
| Battery Type: | LiFePo4 | Nominal Voltage: | 12.8 V |
|---|---|---|---|
| Cycle Life: | More Than 2000times | Brand: | Coslight Or OEM |
| OEM/ODM: | Support Customize | Warranty: | 3 Years |
| Delivery: | Sea, Air Or Express | ||
| High Light: | Coslight Lithium Ion Battery,12v200ah Lithium Ion Battery,48V 30Ah Lifepo4 Battery Pack |
||
Product Information
Quick Detail:
|
Description:
The deep cycle 12v modularized are compact designed with ABS plastic box and built-in BMS to protect the battery from over-charge, over-discharge, over-current, over-voltage, over-temperature and short circuit.
The lithium battery is widely applied to RV, camping car, motorhome, solar system(off-grid system), boat, marine, trolling motor, yatch which give a replacement to your lead acid/AGM/GEL battery.
Applications:
Widely used in Home Appliances, BOATS, SUBMARINES, electric vehicles, Electric Wheelchairs, Electric Power Systems, Solar Energy Storage Systems, Uninterruptible Power Supplies, Solar system,RV,yacht,golf carts storage and car,UPS
Specifications:
| Data Sheet Model-12200 | |
| ELECTRICAL SPECIFICATIONS | |
| Nominal Voltage | 12.8 V |
| Nominal Capacity @ 0.2C | 200 AH |
| Energy | 2560 Wh |
| Resistance | 30 mΩ |
| Cycle Life | 2000+ Cycles @ 1C 80% DOD |
| Efficiency | 99% |
| Self Discharge | <3% per Month |
| Maximum Modules in Series/Parallels | 4S or 4P |
| MECHANICAL SPECIFICATIONS | |
| Width | 170 ± 2 mm |
| Length | 483± 2 mm |
| Height | 240± 2 mm |
| Weight | 22.5 Kg |
| Case Material | ABS+PC |
| Terminal | M8 |
| Enclosure Protection | IP65 |
| CHARGE & DISCHARGE SPECIFICATIONS | |
| Monthly Self Discharge | Less than 2% |
| Efficiency of Charge | 100% @ 0.5 C |
| Efficiency of Discharge | 96~99% @1 C |
| Charge Voltage | 14.6 ± 0.2 V |
| Charge Model CC & CV | 0.2C to 14.6 V , then 14.6 V , charge current to 0.02C |
| Standard Charge Current | 40A |
| Max. Charge Current | 100A |
| Max. Continuous Discharge Current | 100A |
| Peak Discharge Current | 200 A (3S) |
| BMS Discharge Cut-off Voltage | 10 V |
| Charge Temperature | 0~45 ℃ |
| Discharge Temperature | - 20℃ to 60 ℃ |
| Storage Temperature | -20℃ to 45 ℃ |
| COMPLIANCE | |
| Certifications | UN38.3 & CE (battery)UL1642 (cells) IEC62133 (cells) |
| Shipping Classification | UN 3480, CLASS 9 |
