| Place of Origin: | China |
|---|---|
| Brand Name: | Coslight |
| Certification: | UL, CE, FCC, RoHS, Un38.3, CB, IEC62133, MSDS |
| Model Number: | UPS |
| Minimum Order Quantity: | 10pcs |
| Price: | Negotiable |
| Packaging Details: | Wooden Box |
| Delivery Time: | 10-15days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 8000pcs/week |
| Appplication: | Medical/Office/Communication | Backup Time: | User Requirements |
|---|---|---|---|
| Voltage Range: | 208~478Vac | Charging Current: | 10A Max |
| Brand: | Coslight Or OEM | OEM/ODM: | Support Customize |
| Warranty: | 3 Years | ||
| High Light: | 220V Ups Power Backup,800W Ups Power Backup,1KVA Uninterruptible Power Supply |
||
220V 1KVA 800W Office Medical Ups Power Backup With 2 Hours
220V AC to DC 12 Volt mini battery power supply system 5kva 6kva 10kva uninterrupted power supply ups
Product information
Features
DSP Technology: The advanced DSP digital control technology enables UPS more stable performance.
Environment Friendly: This UPS is eco-designed and manufactured to meet the government pollution control requirement of Electronic Products, which means it will cause no harm to environment and human beings in normal usage.
Active input power factor correction (PFC): Digital control of the PFC enables the UPS to keep input power factor above 0.99 to prevent possible electric grid pollution and meanwhile mostly save the cost.
Wide range of input voltage and frequency: We intentionally widen the range of input factors to make sure the UPS can apply to various environment, which will effectively sustain the battery charging even in unstable power environment so that the service life of the UPS could be obviously prolonged.
Zero power switch delay: When the utility power fails, UPS will automatically switch from AC mode to battery mode with no delay, which ensure stable power supply of operating system.
Adaptive Load Management: This technology allows the UPS to be set up at a fixed 50Hz or 60Hz output, while it also can intelligently monitor power usage and automatically shed and reconnect loads in order to prevent generator overload.
Sufficient Expansion Slots: The pre-allocated smart slots enable flexibility in choice of USB cards, AS400 cards, CMC monitoring cards, SNMP cards, RS485 cards and EMD environment monitoring cards.
The load PFC is 0.8: it adapts the features of most current electric equipment and elevates the load-bearing capacity of the machines.
Support the generator: The wide range of input voltage and frequency can effectively separate the harmful electric wave produces by the generator and provide safe and reliable power supply.
Large LCD display
Other
Pure on-line double conversion design
Wide input range
Flexible intelligent monitoring program and strong communication function
Compact design
Precise utility power synchronizing system
Cold start function
Perfect protection
Power Conservation UPS
LCD man-machine conversation platform design
Specifiaction
|
MODEL |
|
1KVA |
1KS |
2KVA |
2KS |
|
Type of equipment |
|
On-line high frequency |
|||
|
Rated capacity |
|
1KVA/800W |
1KVA/800W |
2KVA/1.6KW |
2KVA/1.6KW |
|
Input |
Voltage (Vac) |
80~300V |
|||
|
Power factor |
0.99 |
0.99 |
0.99 |
0.99 |
|
|
Frequency |
40~60 Adjustable |
||||
|
Output |
Voltage(Vac) |
220V/230Vac ± 2% |
|||
|
Frequency |
Synchronize with AC power (AC mode); 50/60Hz ± 0.2Hz (battery mode) |
||||
|
Output Factor |
0.8 |
0.8 |
0.8 |
0.8 |
|
|
Overload rating |
105~150% 30 seconds, then transfer to bypass and alarm |
||||
|
Waveform |
Pure Sine Wave |
Pure Sine Wave |
Pure Sine Wave |
Pure Sine Wave |
|
|
Overload protection |
100%~125%, 1 minutes to transfer to bypass; >150%, 300ms to transfer to bypass |
||||
|
Transfer time |
0ms |
0ms |
0ms |
0ms |
|
|
Battery |
Type |
Sealed lead acid maintenance free |
Sealed lead acid maintenance free |
Sealed lead acid maintenance free |
Sealed lead acid maintenance free |
|
Back up time |
More than 5min(half load) |
External |
More than 5min(half load) |
External |
|
|
Rated voltage |
24V |
36V |
48V |
72V |
|
|
Operating environment |
Working humidity: 20%~95% Working temperature 0~40°C |
||||
|
Dimension(L x W x H) mm |
350*144*230 |
350*144*230 |
425*190*328 |
425*190*328 |
|
|
Net weight |
9.5 |
6 |
18.5 |
10 |
|
|
Communication |
9 Pin D Type Connector (RS232) or USB port (New) |
||||
|
Color of machine case |
Black |
Black |
Black |
Black |
|
